TRENDnet's 48-Port Gigabit PoE+ Managed Layer 2 Switch with 4 shared SFP slots, model TL2-PG484, has 24 x Gigabit PoE+ ports, 24 x Gigabit ports, and 4 x shared SFP slots, a console port, a PoE Power budget of 370 Watts, and an advanced Layer 2 management feature set. This IPv6 ready switch offers traffic management, troubleshooting, access control, and monitoring features.

TRENDnet TL2-PG484 Features

Command Line interface management supported

SNMP (v1, v2c, v3), 802.1X, RSTP, and MSTP support

Supports Port Trunking, Mirroring, IGMP, Static and Dynamic VLAN, and RMON

Private / Voice VLAN, QoS, and bandwidth controls

24 x Gigabit PoE+ ports

24 x Gigabit ports

4 x shared SFP slots and a console port

96 Gbps switching capacity

Smart fans reduce energy consumption

Lifetime Warranty*

TRENDNET TL2-PG484 Specifications

Standards

IEEE 802.1d
IEEE 802.1p
IEEE 802.1Q
IEEE 802.1s
IEEE 802.1w
IEEE 802.1X
IEEE 802.1ab
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3z
IEEE 802.3ab
IEEE 802.3ad
IEEE 802.3af (15.4 Watts / port)
IEEE 802.3at (30 Watts / port)
IEEE 802.3az

Device Interface

24 x Gigabit PoE+ ports
24 x Gigabit ports
4 x shared Gigabit SFP slots
1 x RJ-45 console port
LED indicators
Reset button

Data Transfer Rate

Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit Ethernet: 2000 Mbps (full duplex)

Performance

Switch fabric: 96 Gbps
RAM buffer: 1 MB
MAC Address Table: 16K entries
Jumbo Frames: 10 KB
HOL Blocking Prevention
Forwarding rate: 71.4 Mpps (64-byte packet size)

Management

CLI (Console / Telnet / SSHv2)
HTTP / HTTPS (SSL v2 / 3 TLS) Web based GUI
SNMP v1, v2c, v3
RMON v1
Static Unicast MAC Address
Enable / disable 802.3az Power Saving
LLDP
Virtual Cable Test
IPv6: IPv6 Neighbor Discovery, IPv6 Static IP, DHCPv6, Auto configuration

MIB

MIB II RFC 1213
Bridge MIB RFC 1493
Bridge MIB Extension RFC 2674
SNMPv2 MIB RFC 1907
Ethernet Interface MIB RFC 1643
Ethernet like MIB RFC 2863
Interface Group MIB RFC 2233
MIB Traps Convention RFC 1215
RMON MIB RFC 1757, RFC 2819
802.1p MIB RFC 2674
RADIUS Client Authentication MIB RFC 2618
LLDP-MIB IEEE 802.1ab
Ping MIB RFC 2925, RFC 4560

Spanning Tree

IEEE 802.1D STP (Spanning Tree protocol)
IEEE 802.1w RSTP (Rapid Spanning Tree protocol)
IEEE 802.1s MSTP (Multiple Spanning Tree protocol)

Link Aggregation

Static Link Aggregation
802.3ad Dynamic LACP

Quality of Service (QoS)

802.1p Class of Service (CoS)
DSCP (Differentiated Services Code Point)
Bandwidth Control per port
Queue Scheduling: Strict Priority, Weighted Round Robin (WRR)

VLAN

Multiple management VLAN assignment
Asymmetric VLAN
802.1Q Tagged VLAN
Dynamic GVRP
Up to 256 VLAN groups, ID Range 1-4094
Private VLAN (Protected Ports)
Voice VLAN (10 user defined OUIs)

Multicast

IGMP Snooping v1, v2, v3
Static Multicast Address
Up to 256 multicast entries
MLD Snooping v1, v2

Port Mirror

RX, TX, or Both
One to one
Many to one

Access Control

802.1X Port-Based Network Access Control, RADIUS, TACACS+
Local Dial In User Authentication
DHCP Snooping
Loopback Detection
Duplicated Address Detection
Trusted Host
Denial of Service (DoS)

ACL IPv4 L2-L4 & IPv6

MAC Address
VLAN ID
Ether Type (IPv4 only)
IP Protocol 0-255
TCP / UDP Port 1-65535
802.1p
DSCP (IPv4 only)
IPv6 Address (IPv6 only)

Management Utility

Windows 10, 8.1, 8, 7, Vista, XP, Windows 2003 / 2008 Server

Special Features

PoE+ ports

Power

Input: 100 240 V AC, 50/60 Hz, internal power supply
Consumption: 425.6 W (max.)

PoE

PoE budget: 370 W
802.3at: Up to 30 W per port (ports 1-24)
Mode A: Pins 1,2 for power(+) and pins 3,6 for power(-)
PD auto classification
Over current / short circuit protection

Smart Fan / Acoustics

Quantity: 4
Noise Level: 56 dB(A) (max.)

MTBF

318,350 hours

Operating Temperature

0 45C (32 113F)

Operating Humidity

Max. 90% non-condensing

Dimensions

440 x 430 x 44.45 mm (17.3 x 16.93 x 1.75 in.)
Rack mountable 1U height

Weight

6.61 kg (14.57 lbs.)

Certifications

CE
FCC
UL

Warranty

Lifetime Warranty*

What's Included

TL2-PG484

Quick Installation Guide

CD-ROM (Utility & User's Guide)

Power cord (1.8 m / 6 ft.)

RJ-45 to RS-232 console cable (205.74 cm / 6.75 feet)

Rack mount kit
